Specification |
|
|
Display |
|
|
Screen size |
2.4-inch |
|
Type |
LCD-TFT display screen |
|
Audio |
|
|
Audio output |
1 loudspeaker, 1 buzzer |
|
Network |
|
|
Wired network |
TCP/IP, 10/100Mbps, self-adaptive |
|
Communication protocol |
TCP/IP, ISUP |
|
Interface |
|
|
Network interface |
1 |
|
Lock control |
1 |
|
Exit button |
1 |
|
Door contact input |
1 |
|
TAMPER |
1 |
|
USB |
1 |
|
Capacity |
|
|
Card capacity |
1000 |
|
Fingerprint capacity |
1000 |
|
Event capacity |
100,000 |
|
Authentication |
|
|
Card type |
Mifare 1 card |
|
Card reading distance |
0 to 5 cm |
|
Fingerprint module |
Optical fingerprint module |
|
Fingerprint comparing mode |
1:1 and 1:N |
|
Fingerprint recognition duration |
< 1 s |
|
General |
|
|
Power supply |
12 VDC/1 A |
|
Working temperature |
-10 °C to +55 °C (14 °F to +131 °F) |
|
Working humidity |
10% to 90% (no condensing) |
|
Color |
Silver |
|
Dimensions |
140 mm × 155 mm × 30 mm (5.51" × 6.01" × 1.18") |
|
Self Service Reports (SSR) |
Stand-alone operation, calculate attendance data and export reports via USB interface |
|
Installation |
Wall mounting |
|
Weight |
Gross weight: 0.78 kg (1.72 lbs) Net weight: 0.22 kg (0.48 lbs) |
