14. Specification

Camera

Image Sensor

2 MP CMOS

Max. Resolution

1920 (H) × 1080 (V)

Min. Illumination

0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light

Shutter Time

PAL: 1/25 s to 1/50,000 s,NTSC: 1/15 s to 1/50,000 s

Day & Night

ICR

Angle Adjustment

Pan: 0° to 360°,Tilt: 0° to 90°,Rotate: 0° to 360°

Signal System

PAL/NTSC

Lens

Lens Type

2.8 mm, 3.6 mm fixed lens

Focal Length & FOV

2.8 mm, horizontal FOV: 101°, vertical FOV: 55°, diagonal FOV: 122°;

3.6 mm, horizontal FOV: 84°, vertical FOV: 47°, diagonal FOV: 99°

Lens Mount

M12

Microphone

Pickup Distance

In a radius of up to 5 m

Amount

1

Speaker

Rated Power

2 W

Speaker Range

In a radius of up to 5 m

Illuminator

Supplement Light Type

Smart,IR,White Light

Supplement Light Range

IR: Up to 25 m,White Light: Up to 20 m


Image Settings

Anti-banding, Brightness, Sharpness,

Smart IR

Frame Rate

TVI: 1080p @25 fps/30 fps

Day/Night Mode

Auto/Color

Wide Dynamic Range (WDR)

Digital WDR

Image Enhancement

DWDR, BLC, HLC,

Global

Noise Reduction

3D DNR

White Balance

Auto,

Manual

Audio

Audio Function

Echo Cancellation, AI Noise Reduction, Automatic Gain Control

Interface

Video Output

1 HD analog output

General

Power

12 VDC ± 25%, max.5.3 W,*You are recommended to use one power adapter to supply

the power for one camera.

Material

Plastic
