• Specification

Display

Screen Size

23.8 inch

Active Display Area

527.04 (H) mm × 296.46 (V) mm

Resolution

1920 × 1080

Backlight

E-LED

Pixel Pitch

0.2745 (H) mm × 0.2745 (V) mm

Brightness

250 cd/m²

Viewing Angle

178° (H) / 178° (V)

Color Depth

8 bit ,16.7 M

Contrast Ratio

4000 : 1

Response Time

7 ms

Refresh Rate

Typ. 60 Hz , Max. 100 Hz

Haze

Haze 25%

Reliability

7 × 24 H

Color Gamut

72% NTSC

Interface

Video & Audio Input

HDMI 1.4 × 1, VGA × 1, Audio IN × 1

Video & Audio Output

Speaker × 2 ( 4Ω 2W)

Data Transmission Interface

None

Control Interface

None

Power

Power Supply

DC 12V, 2.0A

Power Consumption

≤ 24 W

Standby Consumption

≤ 0.5 W

Working Environment

Working Temperature

0℃ to 40 ℃ (32 ℉ to 104 ℉ )

Working Humidity

20% to 90% RH (Non-Condensing)

Storage Temperature

-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉ )

Storage Humidity

10% to 90% RH (Non-Condensing)

General

Casing Material

Plastic

VESA

75 mm × 75 mm (4 - M4 × 6 mm)

Bezel Width

2.0 mm (top/left/right), 23.55 mm (bottom)

Product Dimensions (W × H × D)

With base: 539.7 (W) mm × 399.9 (H) mm × 164.72(D) mm

21.25 (W) inch × 15.74 (H) inch × 6.49 (D) inch Without base: 539.7 (W) mm × 327.33 (H) mm × 43.5 (D) mm

21.25 (W) inch × 12.89 (H) inch × 1.71 (D) inch

Package Dimensions (W × H × D)

611 (W) mm × 405 (H) mm × 118 (D) mm

24.06 (W) × 15.94 (H) × 4.65 (D) inch

Net Weight

2.85 ± 0.5 kg

Gross Weight

3.85 ± 0.5 kg

Packing List

Monitor × 1, Base component × 1, Power adapter (12 V, 2 A) × 1, HDMI cable (1.5 m) ×

1, User manual × 1, Multilingual manual × 1

Remarks

The base is included by default.

The product appearance and parameters in this specification may vary from your actual device. Please consult our local sales staff for further information
